Flat Drip Irrigation Tape Production Line/Drip Irrigation Tape Making Machine

Product Description

Basic Info.

After-sales Service

1 Year

Applicable Material

Stainless Steel

Drive Mode

Electric

Warranty

1 Year

Trademark

Comrise Machinery

Transport Package

Customized

Specification

370m/min

Origin

Chinashandong

Product Description

Flat panel emitter drip irrigation tape production line

characteristic: 1. The dropper is injection molded in one go and has a wide and long flow channel. It serves as a filter window and has strong anti clogging performance. 2. Good uniformity of water output. The drip head is directly welded to the drip irrigation pipe, reducing pressure loss and saving water. 3. It can achieve the simultaneous use of water and fertilizer, improve fertilizer utilization efficiency, save labor and fertilizer 4. Adopting a labyrinth flow channel with a certain pressure compensation effect. 5. The dropper is integrated with the pipeline, easy to install and use, low cost, and low investment. 6. Drip irrigation pipes of different specifications are suitable for different irrigation situations, The distance between the dripper and can be adjusted according to the needs of different crops to meet different customers.
This flat dripper irrigation tape production line is our new generation of high-speed thin-wall drip irrigation tape production
line. Used for garden hose manufacturing machine,such products are widely used in crop (such cotton),fruit,vegetabies,trees,flowers and other industries of drip irrigation planting.

No	Item	Specifications
1	Tape Diameter	Φ16mm
2	Tape Wall Thickness	0.2-0.8mm
3	Single Screw Extruder	SJ-75/32
4	Design production Speed	160m/min (300mm spacing distance)
5	Central Line Height	1000mm
6	Dripper Identifying Speed	400 pcs/min
7	Dripper Spacing	100mm-1000mm
8	Punching Speed	2000 pcs/min
9	Punching Method	Mechanical puching
10	Tape Roll Length	500m-2500m
11	Total Installed Power	95 Kw
12	Max Extruding Capacity	160Kg
13	Size of the Line (L×W×H)	25m2m3m
14	Total Line Weight	About 6000kg

Product introduction

Drip head screening, conveying, embedding unit

The screening machine has a diameter of 1580mm and is compatible with both large and small pieces. Centrifugal pneumatic recognition, frequency conversion control. Recognition speed: Droplets<2500. Applicable droplet head size: 23mm * 6mm * 2.1mm, conveying speed>3000 pieces/minute Can adapt to patch compatible lengths of 18MM-20-23-24-25-27-30

Single screw extruder SJ-90/Single screw extruder

(90) Screw, maximum extrusion capacity: 180kg/h. It can adapt to raw material production and 90% recycled material production. Motor: 75kw Huichuan servo or Guomao+Huichuan servo controller Equipped with pressure transmitter, without color code machine. A set of semi-automatic 160mm hydraulic screen changer Gearbox: (Guomao or Jiangzi). Model (250).

Stainless steel vacuum sizing cooling water

Length 4 meters Including dropper attachment sizing device Including vacuum generation control system Including pinhole and hole detection device Including a broken pipe detection device

Stainless steel cooling water tank

Pipe diameter: φ16mm Total length of sink: (6) meters Stainless steel 304 material, adjustable height

hauling machine

Double synchronous belt traction, pneumatic clamping Panasonic servo motor control, motor power 3.0kw Traction speed: 0-450m/min

hole-punching machine

4 workstations for drilling holes Punching machine power: 0.4kw Panasonic servo motor Drilling speed:<4000 pieces/min Supporting vacuum chip suction device

Dual station automatic winding machine

Automatic meter cutting for forming tube strips. 2.0KW * 2 servo motor brand: Panasonic Maximum speed of 450 meters per minute Next step is automatic

FAQ

1,If you want to send engineers to our factory to install and test machines?
Yes, we will send professional engineers to your factory for each set of machines and assist you in installing and testing the machines, providing high-quality installation services.

2,If you have CE, SGS, ISO certificates?
Yes, in addition to these, if you need any other certificates, we can also help you apply.

3,If we purchase your machine, can you provide us with a backup plan for wear and tear?
Yes, we provide high-quality machines with a 1-year warranty, and we will also provide you with 1-year free wear and tear spare parts. Once your machine breaks down or does not work within 1 year and you are unable to resolve it, we will first try to help you find the problem from your written description through phone or other communication tools. Secondly, if the phone solution still doesn't work, our engineers will go to your factory to solve it. At the same time, they will teach you relevant repair experience.

4,If you support Trade Assurance Payment?
Yes, it is. 100% support.

5,How about the payment method?
TT, LC,Western Union,Telgram,sight letter of credit or trade guarantee.

Welcome to inquire
